18000 BTU Mini Split Air Conditioner – Heat Pump – SENA/18HF

From 2,199.99$

Installation kit

Clear

SKU: SENA-18HF/Z Categories: Air conditioners & heat pumps Mini Split, Mural, Single zone Tags: AURA Series (-30°C), WI-FI Product

Description

20 SEER (CEE Tier 2)
With Heat Pump (Up to -30C / -22F)
Energy Star Certified
Whisper Technology (Ultra Quiet)
Refrigerant Leak Detection
Inverter Technology
Silver Ion Filter (Anti-Microbial)
Vertical Swing Function
Built-In De-humidification Function
Follow Me Function (Remote with Built-In Thermostat)
Low Ambient Cooling (Up to -30C / -22F)
Self-Cleaning Mode
PTC Heat Belt and Pan
Bucket Free Outdoor Design
Self Diagnosis System

Informations

Control the comfort of virtually any room or space with our high efficiency cold climate heat pumps. As part of our aura series, our Mini Split wall mounted air conditioners provide you with efficient heating (down to -30C / -22F) and cooling, with up to 25 SEER and 10.3 HSPF on heating. Enjoy constant control and comfort with minimal power consumption thanks to our DC inverter, variable speed compressor, with energystar certification.

Technical specifications

Senville Model #			SENA/18HF
Power supply		Ph-V-Hz	208-230V~ 60Hz, 1Ph
Cooling	Capacity	Btu/h	17000
	Input	W	1360
	Rated current	A	5.95
	EER	BTU/w	12.5
	SEER	BTU/w	20
Heating	Capacity	Btu/h	18000
	Input	W	1685
	Rated current	A	7.4
	COP	W/W	3.13
	HSPF4	BTU/w	10.3
	HSPF5	BTU/w	8.8
Outdoor Operating Temp.		C/F	-30/-22
MINIMUM CIRCUIT AMPACITY		A	18
MAX.FUSE		A	25
	Type		ROTARY
	Brand		GMCC
Indoor Air Flow (High/Medium/Low)		m3/h	950/750/600
Indoor Air Flow (High/Medium/Low)		CFM	599/411/353
Indoor Noise Level (High/Medium/Low)		dB(A)	45.5/36/26.5
Indoor unit	Dimension (WDH)	mm	990x218x315
	Dimension (WDH)	inch	38.98×8.58×12.40
	Packing (WDH)	mm	1065x300x400
	Packing (WDH)	inch	41.93×11.81×15.75
	Net/Gross weight	kg	12.2/15.8
	Net/Gross weight	lbs	26.89/34.83
Outdoor noise level		dB(A)	57.5
Outdoor unit	Dimension(WDH)	mm	845x363x702
	Dimension(WDH)	inch	33.27×14.29×27.64
	Packing (WDH)	mm	965x395x755
	Packing (WDH)	inch	37.99×15.55×29.72
	Net/Gross weight	kg	48.7/52.2
	Net/Gross weight	lbs.	107.4/115.1
Refrigerant Type		g	R410A/1950
Refrigerant Type		oz	R410A/68.8
Refrigerant Precharge		ft	25
Additional Charge For Each ft		oz	0.161
Refrigerant piping	Liquid side/ Gas side	inch	1/4″ & 1/2″
	Max. refrigerant pipe length	m	30
	Max. refrigerant pipe length	ft	98
	Max. difference in level	m	20
	Max. difference in level	ft	66
Connection wiring			16AWG*4 Stranded, unshielded
